SLIM FOLD SLIDE THERMAL SYSTEM
| Technical characteristics | |
|---|---|
| Bottom track height | 55 mm |
| Floor step | 0 / 12 / 28 / 43 / 55 mm |
| Frame Height, Horizontal Top | 76 / 100 mm |
| Frame Height, Vertical | 63 mm |
| Frame Width | 94 mm |
| Tile Insert | 20 mm |
| Floor Typology | Step, Submerged |
| Riding Typology | Bottom Rolling |
| Sliding / Alignment rollers | Stainless Steel |
| Sash Height, Vertical | 40 mm |
| Sash Height, Horizontal | 40 mm |
| Sash Width | 80 mm |
| Centre Mullion Height | 94 mm |
| Max. Weight per Sash | 150 Kg |
| Max. Sash Width | 1500 |
| Max. Sash Height | 4000 |
| Opening type | Fold Slide |
| Glazing Width Possibilities | 38/50mm |
| Maximum Locking Points | 6 |
| Sealing Type | 6 Gaskets |
| Performances | |
|---|---|
| Fabrication Thermal Transmittance EN ISO 10077-2 (Uw) | ≥0.9 W/(m2K) |
