MINIMAL FOLD SLIDE COLD SYSTEM
| Technical characteristics | |
|---|---|
| Bottom track height | 32 mm |
| Floor step | 24 mm |
| Frame Height, Horizontal Top | 68 mm |
| Frame Height, Vertical | 30 mm |
| Frame Width | 60 mm |
| Floor Typology | Step |
| Riding Typology | Top Rolling |
| Sliding / Alignment rollers | Nylon / Stainless Steel |
| Sash Height, Vertical | 30 mm |
| Sash Height, Horizontal | 30 mm |
| Sash Width | 60 mm |
| Centre Mullion Height | 74 mm |
| Max. Weight per Sash | 100 Kg |
| Max. Sash Width | 1200 |
| Max. Sash Height | 3000 |
| Opening type | Fold Slide |
| Glazing Width Possibilities | 32mm |
| Maximum Locking Points | 5 |
| Sealing Type | 4 Gaskets |
FLOOR
MIDDLE
CONSTRUCTION
